Desktop Label Printer SRP-E770III
The BIXOLON SRP-E770III offers a design that is synonymous with Direct Thermal barcode labelling. BIXOLON’s entry-level 4-inch (106mm) Direct Thermal printer offers a solution that ensures easy out-of-box setup and recognition of a range of media thanks to its Smart Media detection.Locally wired or wired Network, the 203 dpi printer supports market leading programming languages and offers quality output at up to 5 ips (127mm/s) print speed.Able to handle the market leading programming languages and supported by a range of drivers and Label Artist™ design software, the SRP-E770III printer ensures complexities are minimised and budgets maximized.
The BIXOLON SRP-E770III offers a design that is synonymous with Direct Thermal barcode labelling. BIXOLON’s entry-level 4-inch (106mm) Direct Thermal printer offers a solution that ensures easy out-of-box setup and recognition of a range of media thanks to its Smart Media detection.Locally wired or wired Network, the 203 dpi printer supports market leading programming languages and offers quality output at up to 5 ips (127mm/s) print speed.Able to handle the market leading programming languages and supported by a range of drivers and Label Artist™ design software, the SRP-E770III printer ensures complexities are minimised and budgets maximized.
| • • SPECIFICATION | • • • • • • • • • • |
|---|---|
| Print Method | Direct Thermal |
| Print Speed | Up to 5 ips (127 mm/sec) |
| PRINT RESOLUTION | 203 dpi |
| PRINT WIDTH | Up to 104 mm |
| PRINT LENGTH | Up to 1,000 mm |
| SENSOR | Head open, Reflective (adjustable), Transmissive |
| Media Type | Black Mark, Continuous, Fan-Fold, Gap, Notch |
| Media Width | 42 ~ 106 mm |
| Media Roll Size | Up to 130 mm |
| Media Thickness | 0.06 ~ 0.20 mm |
| Supply Method | Easy Paper Loading |
| Inner Core | 25.4 ~ 38.1mm |
| DIMENSION (W X D X H IN MM) | 189 x 221 x 171 mm |
| Weight | 1.47kg (3.24 lbs.) |
| Electrical | 50/60Hz, EnergyStar Certified, External Power Adaptor 100-240V AC |
| Memory | 64 MB SDRAM, 128 MB Flash |
| Interface | • • • • • • • • • • |
| Standard Interface | USB |
| Optional Interface | USB + Ethernet, USB + Serial |
| Real Time Clock | Supported |
| • • ENVIRONMENTAL | • • • • • • • • • • |
| Operating Temperature | Operating: 0 ~ 40℃ (32 ~ 104℉), Storage: -20 ~ 60℃ (-4 ~ 140℉) |
| Operating Humidity | Operating: 10 ~ 80% RH, Storage: 10 ~ 90% RH |
| Emulation | BPL-E™ (EPL), BPL-Z™ (ZPLII), SLCS™ |
| Driver / Utility | Bartender Ultralite for BIXOLON, Label Artist-II™, Linux / Mac CUPS Driver, OPOS Driver, Utility Program, Virtual COM USB / Ethernet Driver, Windows Driver (Europlus / Seagull) |
| SDK / Plugin | Android / iOS / Windows SDK, Chrome SDK, Linux SDK, Xamarin SDK |
| Application | Label Artist™ Mobile (Android, iOS), mPrint App (iOS) |
| • •Fonts/Graphics/Symbologies | • • • • • • • • • • |
| Fonts | 10 SLCS™, 16 BPL-Z™, 23 Code Page, 5 BPL-E™, One BPL-Z™, One SLCS™, Unicode supported (UTF-8, UTF-16LE,UTF-16BE) |
| Graphics | Supporting user-defined fonts, graphics, formats, and logos |
| Barcode Symbologies | • • • • • • • • • • |
| 1D | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar (RSS-14), IMB, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, Standard 2-of-5, UPC-A, UPC-E, UPC/EAN extensions |
| 2D | Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 |
| Optional Accessories | Peeler |
| BRAND |
